OCTG Premium Connection

SIZE RANGE AND APPLICATIONS

HSM-1 CASING STRUCTURE FEATURES

Improved buttress thread

5TPI

1:10 cone to metal seal

Reverse torque shoulder (-15°)

Internal Flush

HSM-1 tubing structure features

Lead:6TPI, 8TPI, taper:1:16

Tapered metal-to-metal seal

-20° reverse angle torque shoulder

Internal flush design

CASING AND TUBING PERFORMANCE DATA

PREMIUM CONNECTION	HSM-1 TUBING	HSM-1 CASING
MINIMUM INTERNAL YIELD PRESSURE (% PIPE BODY)	100%	100%
EXTERNAL PRESSURE (% PIPE BODY)	100%	100%
TENSILE EFFICIENCY (% PIPE BODY)	100%	100%
COMPRESSION (% PIPE BODY)	40%	40%
BENDING (/100FT)	10%	10%

Size Availability

2 3/8” TO 13 5/8”

Structure Features

Improved buttress thread

Reverse shoulder tapered metal to metal seal

Main Applications

Deep well

High pressure gas well

Options

Special Bevel

Special Clearance

HSM-2 CASING STRUCTURE FEATURES

Hooked thread

Tapered metal-metal seal

-15° torque shoulder

Internal flush

Size Availability

2 3/8” TO 13 3/8”

Structure Features

Hook thread

Reverse shoulder

Tapered metal-to-metal seal

Main Applications

Horizontal & extended reach wells

High pressure gas well

Options

Special Bevel

Special Clearance

CASING AND TUBING PERFORMANCE DATA

PREMIUM CONNECTION	HSM-2 TUBING	HSM-2 CASING
MINIMUM INTERNAL YIELD PRESSURE (% PIPE BODY)	100%	100%
EXTERNAL PRESSURE (% PIPE BODY)	100%	100%
TENSILE EFFICIENCY (% PIPE BODY)	100%	100%
COMPRESSION (% PIPE BODY)	100%	60%
BENDING (/100FT)	20%	20%

HSN STRUCTURE FEATURES

90° positive torque shoulder

API Buttress

Internal flush

Size Availability

4 1/2” TO 13 3/8”

Structure Features

Buttress thread

90° shoulder

Main Applications

Geothermal

Shale

Heavy Oil

Drilling with casing

Options

Special Bevel

Special Clearance

CASING AND TUBING PERFORMANCE DATA

PREMIUM CONNECTION	HSN CASING
MINIMUM INTERNAL YIELD PRESSURE (% PIPE BODY)	100%
EXTERNAL PRESSURE (% PIPE BODY)	100%
TENSILE EFFICIENCY (% PIPE BODY)	100%
COMPRESSION (% PIPE BODY)	100%
BENDING (/100FT)	20%

HSFJ STRUCTURE FEATURES

Hooked thread: 3”/25°

Thread lead: 6TPI, taper : 1:16 to 1:10

Seal: tapered, internal (-30°), external (1:5)

Shoulder: -15° external shoulder

Size Availability

2 7/8” TO 11 3/4”

Structure Features

Flush Joint with external & internal seals

Main Applications

Flush connection for max clearance

CASING AND TUBING PERFORMANCE DATA

PREMIUM CONNECTION	HSFJ
MINIMUM INTERNAL YIELD PRESSURE (% PIPE BODY)	100%
EXTERNAL PRESSURE (% PIPE BODY)	100%
TENSILE EFFICIENCY (% PIPE BODY)	55%-65%
COMPRESSION (% PIPE BODY)	20%-25%
BENDING (/100FT)	10%

HSKS STRUCTURE FEATURES

Coarse thread: 0° load flank, ensure tension efficiency; 30° stabbing flank, easy stabbing

Lead: 3TPI;taper:1:7.5, quick running

Enhanced thread height, no cross-threading

Size Availability

13 3/8” TO 20”

Structure Features

Flush Joint with external & internal seals

Main Applications

Flush connection for max clearance

Options

Special Bevel

Special Clearance

CASING AND TUBING PERFORMANCE DATA

PREMIUM CONNECTION	HSN CASING
MINIMUM INTERNAL YIELD PRESSURE (% PIPE BODY)	100%
EXTERNAL PRESSURE (% PIPE BODY)	100%
TENSILE EFFICIENCY (% PIPE BODY)	100%
COMPRESSION (% PIPE BODY)	70%
BENDING (/100FT)	20%
